Three Phase 32Amp 22KW EV Charger Station

Scurta descriere:

Model: MIDA-EVST-22KW
Curent nominal: 32Amp
Tensiune de funcționare: AC 400V trifazat
Frecvența nominală: 50 / 60Hz
Material carcasă: aliaj de aluminiu
Grad de protecție: IP55

Articol		Stație de încărcare AC EV de 22KW
Curent nominal		32Amp
Tensiunea de funcționare		AC 480V Trifazat
Frecvența nominală		50 / 60Hz
Protecție împotriva scurgerilor		Tipul B RCD / RCCB
Material Shell		Aliaj de aluminiu
Indicație de stare		Indicator de stare LED
Funcţie		Card RFID
Presiune atmosferică		80KPA ~ 110KPA
Umiditate relativă		5% ~ 95%
Temperatura de Operare		-30 ° C ~ + 60 ° C
Temperatura de depozitare		-40 ° C ~ + 70 ° C
Grad de protecție		IP55
Dimensiuni		350mm (L) X 215mm (W) X 110mm (H)
Greutate		9,0 KG
Standard		IEC 61851-1: 2010 EN 61851-1: 2011 IEC 61851-22: 2002 EN 61851-22: 2002
Certificare		TUV, aprobat CE
Protecţie		1. Protecție peste și sub frecvență2. Protecție împotriva curentului 3. Protecție la curent de scurgere (reporniți recuperare） 4. Protecție la supratemperatură 5. Protecție la suprasarcină (recuperare auto-verificare) 6. Protecție la sol și protecție la scurtcircuit 7. Protecție la supratensiune și sub tensiune 8. Protecția iluminatului

The 22KW wall-mounted charging station is a device used to charge electric vehicles and is capable of providing up to 22 kW of output power. This type of charging station is usually mounted on the wall and is easy to install and use in parking lots, parking garages, car service stations and other locations.

1, The charging station typically has the following features.

2, High power output: up to 22 kW of output power can quickly charge electric vehicles.

3, High safety performance: With various protection functions such as over-voltage, over-current, short-circuit, under-voltage and over-temperature to ensure charging safety.

4, Convenience: wall-mounted design does not occupy ground space and is easy to install.

5, Good compatibility: support multiple charging standards and connection methods, suitable for different types of electric vehicles.

High degree of intelligence: supports remote monitoring and management, capable of intelligent charging management and billing and other functions.

It should be noted that the 22KW wall-mounted charging station needs to be connected to the power grid to work properly, and needs to have the corresponding installation conditions and qualification. During installation and use, relevant safety regulations need to be observed to ensure safe use.
