Tesla Supercharger To Ccs Adapter
The Tesla CCS 1 AC/DC charger can be mounted on the vehicle’s exterior or embedded within the vehicle’s interior. The battery management system is linked to the charger. This system makes certain that the battery cells are correctly charged until the high voltage (HV) requirements are met. The HV battery is required to power the traction motor during operation. It also provides 12 V to the vehicle’s other electronic modules via a converter.
Adapter For Tesla Turbocharged engine To Ccs The AC/DC charger Tesla CCS 1 can be mounted on the vehicle’s exterior or embedded within the vehicle’s interior. The battery management system connects to the charger. This system makes sure that the battery cells are correctly charged until the high voltage (HV) requirements are met. During operation, the HV battery is required to power the traction motor. It also provides 12 V to the vehicle’s other electronic modules via a converter. Depending on the charging mode and technology (slow, medium, or fast) (wired or wireless)
Main features of the tesla to ccs adapter
1.Charging at up to 1000 volts and 200 amps
2.The peak power is restricted to 150 KW.
3.The product includes a temperature safety switch.
4.The range replenishment rate is approximately 155 miles (250 kilometres) per 20 minutes.
5.This adapter is compatible with the Model 3, S, X, and Y.
Specifications :
Power: 175kW maximum rating.
400A rated current
Titanium Copper Alloy is the conductor material.
Shell Polyoxymethylene is the material (Insulator inflammability UL94 VO)
Temperature range: -30°C to 50°C.
Temperature range for storage: -30°C to 85°C
5001000V rated voltage
Dual temp. kill switch for security. When the adapter reaches 90oC, charging stops.
Silicon rubber sealing gasket
Anti-Theft Lock for added security.
CE, TUV, RoHS, and ETL certifications are available (in the process)
IP55 (Protection against dirt, dust, oil, and other non-corrosive materials). Complete protection against contact with enclosed machinery. Water protection, up to water projected by a nozzle against the enclosure from any direction.
Key benefits
- Solve the inconvenience of travel charging、Restricted travel
- Unrestricted by limited charging posts
- Fast time frame and short charging time
How to use :
The product manual includes a step-by-step guide for easy use.
Simply connect your Thunderstorm Plug to the charging station first, then to your Tesla. Simply authorize it from your car or phone to remove it from your vehicle.
About us
We are China’s only manufacturer with the same function as the Tesla adapter and a patent. Our products are less expensive than the original while providing the same performance.
Olink is particularly interested in producing custom wire harnesses, cable assemblies, USB cables, car audio connectors, sockets, wafers, and terminals.
We provide a complete line of automotive connectors and sockets for all popular automobiles.
