HPC Ev Charger Connector Adapter

(1) The dust pollution test has a limited impact on the overall calorific value of the IP qualified charging gun. The pin temperature increases by about 3K on average, and the surface temperature of the cable and gun body changes little
(2) The high temperature and humidity environment will accelerate the temperature rise process of the charging gun, but it has little impact on the temperature rise of the charging gun terminal, and has a little impact on the temperature of the charging gun cable surface and the gun body surface. The impact of the high temperature and humidity environment on the heating of the charging gun is that it accelerates the temperature rise process, the temperature of the cable and the gun body surface rises slightly, and the pin temperature does not change significantly
(3) Repeated plugging test has a significant impact on the heating condition of the charging gun, and the charging gun after long-term use has certain potential safety hazards
(4) Although the conductivity of the brass pin is different from that of the tin bronze pin, there is little difference in heating. For the different thickness of the silver plating layer, the pin temperature of the charging gun made of the tin bronze silver plated 5um pin has increased by 16K on average, which is the same as that of the silver plating layer 3 μ The pin temperature of M charging gun has increased by about 12K on average. This indicates that the wear of silver plating layer after plugging test has aggravated the heating of charging gun with thick silver plating layer. This reflects the protective effect of silver plating layer on the pin. The thickness of silver plating layer has a certain impact on the heating of charging gun. The thicker the silver plating layer, the lower the working temperature of charging gun

Basic Info.
Model NO:TH fast ev charger
Altitude：Less Than 2000m
Operation Temperature:–20ºC–+70ºC
Constant Power Output Range：(250-1000V)20kw
Transport Package:Wooden Case
Specification：550*800*1950mm
Trademark:OLINK
Origin：China
HS Code:8504401999
Production Capacity：100 Sets / Month

Mode 1 is plugged into a domestic AC outlet, but it is usually not allowed in most areas, because mode 1 has no special safety electronic equipment.
Mode 2 also plugs into a standard household AC outlet and includes these safety features in its ICCB.
Mode 3 plug in wall box or charging station for AC charging. It does not include an ICCB. In Europe, consumers often need to bring their own type 3 cable to use their own public AC charging station.
Mode 4 is reserved for high-speed DC charging in the charging station
