High Power Charging Gun
CHARGERMAN national standard DC charging gun is a product developed in accordance with gb/t 20234-2015 standard and has obtained the CQC standard license; CHARGERMAN independently researched and developed the design, based on the “Minimalism” design concept, which is generous and concise, with elegant color matching on the appearance surface; The handle design conforms to the principle of ergonomics and feels comfortable; The unique heat dissipation structure design greatly reduces the working temperature of the charging gun; Built in switch and electronic lock module, more stable quality and performance, and more convenient for maintenance and replacement; Locking bayonet locking device can ensure stable and reliable connection.
Three signal indicators
Ergonomic design TPU rubber coated handle for comfortable grip
Independently developed wire rod by chargerman
Rated voltage: 250V AC
Rated current: 13a /20a/32a/70a
Contact resistance: ≤ 0.05 M Ω
Insulation resistance: ≥ 500 m Ω
Withstand voltage: 2500V AC
Mechanical life: ≥ 10000Cycles (no – load)
Plugging force: F ＜ 100N
Protection grade: IP67
Ambient temperature: -30 ℃ ~ +50 ℃
Humidity: 5%~95% (40 ℃)
Flame retardant grade: UL94V-0
Electrical parameters
Voltage ballpark: 750 V dc/1000 V DC
Rated current: 350 a, 400 a, 500 a, and 600 a.
500 metres of insulation resistance (under normal temperature)
Standing voltage: 3500 ac
PC inclosure
The T2 red copper pin portion
