CCS1 TO CCS2 Car Adapter
Item: CCS 2 to CCS 1 EV adapter CCS Combo 2 plug to CCS Combo 1 plug converter If your EV has a European CCS Combo 2 plug for DC fast charging and you want to use DC fast chargers in the US, Korea or Taiwan, this adapter is for you! This heavy-duty adapter allows you to charge your CCS Combo 2 vehicle at full speed on all CCS Combo 1 fast charging stations. Designed for 150 amps and 600 volts DC DUOSIDA 150A CCS1 to CCS2 adapter
The CCS1 TO CCS2 Car Adapter is a versatile solution that seamlessly bridges the gap between connectors. Designed to convert a CCS Combo 2 plug into a CCS Combo 1 plug, this adapter offers enhanced compatibility for electric vehicles (EVs). If your EV is equipped with a European CCS Combo 2 plug for DC fast charging and you plan to utilize DC fast chargers in the US, Korea, or Taiwan, this adaptor is tailored to your needs. It empowers you to efficiently charge your CCS Combo 2 vehicle at maximum speed on any CCS Combo 1 fast charging station.
The 150A CCS1 to CCS2 converter is engineered to manage 150 amps and 600 volts of DC power, providing a robust and reliable charging experience. The charging plugs adhere to strict standards for quality and compatibility. The COMBO1 plug complies with 62196-3 IEC2014 SHEET 3-llB, while the COMBO 2 plug meets the 62196-3 IEC 2011 ARKUSZ 3 lm specifications.
Product Parameter
Function: Converts CCS Combo 2 plug to CCS Combo 1 plug
Compatibility: European CCS Combo 2 plug to enable charging with CCS Combo 1 fast charging stations in the US, Korea, or Taiwan
Charging Speed: Supports full-speed charging for CCS Combo 2 vehicles on CCS Combo 1 stations
DUOSIDA 150A CCS1 to CCS2 Converter:
Maximum Current Handling: 150A (Amperes)
Maximum Voltage Handling: 600V (Volts) DC
Plug Compatibility: COMBO1 (Meets 62196-3 IEC2014 SHEET 3-llB), COMBO 2 (Meets 62196-3 IEC 2011 ARKUSZ 3 lm)
Housing Material: Thermoplastic flame retardant grade UL94V-O
Contact Material: Copper alloy with silver plating
Mechanical Life: 10,000 plug in/out cycles without load
Impact Resistance: Withstands impact from falling at 1m height and exceeding pressure by 2t
Operating Temperature: -30°C to +50°C
IP Rating: IP65 (Dust-tight and protected against water jets)
Insulation Resistance: > 2000MΩ at DC1000V
Temperature Increase at Terminals: 50 K
Maximum Operating Voltage: 3200V
Features:
Solid Housing Design: The CCS1 to CCS2 Car Adapter features a robust housing design that ensures long-term durability and reliability.
Safety Focus: With an integrated insulated safety head, this adapter prioritizes user safety by preventing unintended direct contact during usage.
Mechanical Reliability: Designed for lasting performance, the adapter can confidently withstand 10,000 plug in/out cycles without load, showcasing its mechanical resilience.
Rugged Endurance: Engineered to endure external force impacts, including falls from up to 1 meter and pressures exceeding 2 tons, the adapter excels in tough scenarios.
Temperature Tolerance: Operating seamlessly within a wide temperature range of -30°C to +50°C, this adapter adapts to diverse environmental conditions.
High-Quality Materials: Crafted with premium thermoplastic flame retardant material adhering to UL94V-O standards, the housing boasts a copper alloy contact bushing with silver plating for enhanced conductivity.
Smooth Insertion and Extraction: User-friendly design ensures a smooth insertion and extraction process, requiring a force of 100N for optimal usability.
IP65 Protection: The adapter holds an IP65 protection rating, effectively safeguarding against dust and water ingress for sustained performance.
High Current Rating: With a substantial 150 A rated current, this adapter seamlessly accommodates high-speed charging demands.
Insulation Resistance: Demonstrating exceptional insulation capabilities, the adapter offers insulation resistance exceeding 2000MΩ at DC1000V.
Minimal Heat Generation: Ensuring a safe charging environment, the temperature increase at terminals is limited to a mere 50 K.
Optimal Voltage Handling: Excelling in voltage management, the adapter confidently manages a maximum operating voltage of 3200V and a 1000VDC operating voltage.
Use your electric vehicle charging experience with the CCS1 TO CCS2 Car Adapter and the high-performance DUOSIDA 150A CCS1 to CCS2 converter. Enjoy seamless charging and enhanced compatibility, all backed by rigorous quality standards and advanced safety features.
